Panthëon-Audio is proud to distribute the complete line of
chokes, audio output transformers and power transformers from
MagneQuest. Below is a partial listing of the MQ lineup; this
will be added to shortly. Please drop me a line if you have any
questions. Average turn around is two to four weeks as these are
custom made, hand-wound irons by Mike LaFevre in the best tradition
of Peerless & Acrosound. Price per Pair in USD.
Shipping additional. Please inquire.
UPDATE: As of 2019,
no more orders are being taken at this time
Sadly, Mike died in 2023 and the company is no longer
building transformers
| MQ~Peerless
Push-Pull output transformers |
| S-240-A |
M6 5K p-p; 4, 8, 16 ohms
taps |
450.00 |
| S-240-A |
Pinstripe 5K p-p; 4, 8,
16 ohms taps |
600.00 |
| S-240-A |
Permalloy 5K p-p; 4, 8,
16 ohms taps |
800.00 |
| S-245-A |
M6 3K p-p; 4, 8, 16 ohms taps
|
450.00 |
| S-245-A |
Pinstripe 3K p-p; 4, 8, 16 ohms
taps |
600.00 |
| S-245-A |
Permalloy 3K p-p; 4, 8, 16 ohms
taps |
800.00 |
| |
|
|
| MQ Single-Ended
Air Gapped output transformers |
| DS-025 |
2.5K;16, 8 and 4 ohms tap, 25W,
60 mA |
360.00 |
| DS-050 |
5K; 16, 8 and 4 ohms tap, 20W,
40 mA |
360.00 |
| FS-030 |
3K;16, 8 and 4 ohms tap, 40W,
60 mA |
720.00 |
| TFA-204 |
3K;16, 8 and 4 ohms tap, 8W, 60
mA |
250.00 |
| |
|
|
| MQ Single-Ended
Parafeed output transformers |
| TFA-2004 |
M4 3K:16, 8 & 4 ohm taps,
15w max |
300.00 |
| TFA-2004 |
Permalloy 3K:16,8 & 4 ohm
taps, 12w max |
600.00 |
| EXO-036 |
Permalloy 2.5K:16 ohms, 3 watts
max |
300.00 |
| EXO-035 |
Permalloy 2.5K: 8 ohms, 3 watts
max |
300.00 |
| EXO-045 |
Permalloy 5K:8 ohms, 2 watts max |
300.00 |
| EXO-046 |
Permalloy 5K:16 ohms, 2 watts
max |
300.00 |
| EXO-050 |
Permalloy 5K:16,8 or 4 ohms, 20watts
max |
700.00 |
| |
|
|
| MQ Plate Chokes |
| BCP15 |
50mA, 40H, 550 ohms DCR |
100.00 |
| B.A.C. 100 |
100mA, 48H |
300.00 |
| EXO-01 |
20 mA, 100H, 985 ohms DCR |
110.00 |
| EXO-010 |
10 mA, 276H, 850 ohms DCR |
150.00 |
| EXO-03 |
60 mA, 30H, 344 ohms DCR |
150.00 |
| EX0-99 |
10mA, 750H (2 coils in series),
20 mA, 187 H (two coils in parallel) |
198.00 |
| |
|
|
| Special Purpose
Chokes |
| EXO-173 |
M6, center tap, phase splitting
duties |
198.00 |
| EXO-173 |
M6\Ni Pinstripe in brass channel
Frames |
250.00 |
| EXO-173 |
Nickel in Brass Channel
Frames |
300.00 |
| BCP16 Ni GC |
Grid choke |
150.00 |
| BCP16 |
M6 GC, Grid choke |
99.50 |
| |
|
|
MagneQuest Transformer product list for download
• 2005-2006 MQ list.doc (in Revision)
